EXB-V4V823JV Technical Specifications: Core Parameters and Selection Guide for Panasonic 82kΩ Resistor Network

Published 31

In the field of electronic design in 2025, the selection accuracy of resistor networks directly determines the final performance and reliability of the circuit board. Data shows that over 67% of hardware engineers have been forced to spin their boards during the prototyping stage due to mismatched resistor network parameters. Today, we will focus on a highly representative product from Panasonic—EXB-V4V823JV, an 82kΩ isolated resistor network, providing an in-depth analysis of its core technical parameters and practical selection key points. Whether you are designing a precision voltage divider circuit or seeking a stable matching resistor solution for signal conditioning modules, this data-driven selection guide will provide you with a clear decision path.

In-Depth Analysis of Core Specifications

Detailed Technical Specifications of EXB-V4V823JV: Panasonic 82kΩ Resistor Network Core Parameters and Selection Guide

Basic Electrical Parameters: Resistance, Tolerance, and Temperature Coefficient

The core electrical parameters of the EXB-V4V823JV are the primary considerations for selection. The device has a nominal resistance of 82kΩ (82000Ω), which belongs to the E24 standard series value, with a tolerance of ±5%, making it suitable for high-volume application scenarios with moderate precision requirements but high cost sensitivity. Its temperature coefficient of resistance (TCR) is ±200ppm/°C, meaning that within the operating temperature range of -40°C to +85°C, the maximum resistance drift is approximately 2.05kΩ. For conventional environments such as industrial control and consumer electronics, this specification fully meets the requirements; however, for precision measurements or wide-temperature-range applications, engineers need to evaluate whether this thermal drift is within the system's acceptable limits.

Package Structure and Power Characteristics: Dissipation and Layout Advantages of the 0606 Size

From a physical structure perspective, the EXB-V4V823JV utilizes a standard 0606 package (1.6mm × 1.6mm), integrating 2 independent resistors internally with optimized pin pitch suitable for high-density PCB layouts. Its rated power is 0.063W (per resistor). With the obvious trend toward miniaturization, this power rating meets the needs of most signal-level circuits. Notably, the device uses a thick film process and possesses excellent anti-sulfuration characteristics, meeting the long-term reliability requirements of industrial environments.

R1_A (1) R2_A (2) R1_B (4) R2_B (3) R1: 82kΩ R2: 82kΩ EXB-V4V823JV

Circuit Topology and Isolation Design: Typical Application Scenarios for 2-Resistor Isolated Networks

The EXB-V4V823JV utilizes an isolated (ISOL) circuit topology, meaning its two internal 82kΩ resistors are completely independent with no common terminal connection. This design provides engineers with maximum circuit flexibility, enabling its use in constructing matching resistor pairs for differential amplifiers, voltage divider networks for ADC front-ends, or as feedback resistors for operational amplifiers. Compared to integrated resistor arrays (such as bussed types), the isolated topology effectively avoids crosstalk issues, exhibiting more stable performance in high-frequency signal processing. If your design requires maintaining precise ratios between two independent channels, this topology is the ideal choice.

Selection Decision Framework: 5 Steps to Confirm if EXB-V4V823JV Fits Your Design

Step 1: Match Resistance Requirements with System Accuracy Budget

First, clarify whether the nominal resistance required by the circuit is 82kΩ and define the maximum resistance deviation allowed by the system. If your design's tolerance requirement is within ±5%, this device is directly applicable; if higher precision (such as ±1%) is required, you need to consider the high-precision version of the EXB-V4V823JV series or choose discrete precision resistors. Please make a trade-off based on your accuracy budget.

Step 2: Verify Power and Thermal Resistance

Calculate the maximum power dissipation of the resistor under actual operating conditions. For example, if the voltage across the resistor is 12V, the power dissipation P = 12² / 82000 ≈ 1.76mW, which is far below the rated value of 0.063W, leaving ample thermal safety margin. However, in high-temperature environments (such as above +70°C), double-check against the derating curve to ensure long-term operational stability.

Step 3: Package Compatibility and PCB Layout Planning

Confirm whether the PCB design reserves the 0606 footprint and if the spacing between adjacent components meets soldering process requirements. The EXB-V4V823JV has good lead coplanarity, suitable for reflow soldering processes, but glue reinforcement is recommended for high-vibration applications. Ensure that sufficient heat dissipation and maintenance space are allocated during layout planning.

Step 4: Environmental Stress and Reliability Assessment

Evaluate environmental factors such as temperature cycling, humidity, and sulfur gases in the application scenario. Thick-film resistor networks perform better than thin-film resistors in moisture and sulfuration resistance, but actual testing is still required to verify long-term stability in extreme environments. You can refer to the official reliability test data provided by Panasonic to match your actual application environment.

Step 5: Balance Cost and Lead Time

Finally, comprehensively compare the total cost of this device against discrete solutions. When a single board requires more than two 82kΩ resistors and layout space is tight, the integration advantage of the EXB-V4V823JV is significant, effectively reducing placement counts and inspection costs. At the same time, verify the distributor's lead time to avoid project delays. Panasonic's official industrial website provides complete technical documentation and CAD model downloads, and mainstream component distributors have stock available, making it convenient to obtain samples and technical support.

Summary and Selection Action Checklist

Key Parameter Quick Reference TableEXB-V4V823JV Specifications
Resistance82kΩ
Tolerance±5%
Temperature Coefficient (TCR)±200ppm/°C
Power Rating0.063W/resistor
Package0606 (1.6 × 1.6mm)
Circuit Topology2-Resistor Isolated
Operating Temperature-40°C ~ +85°C

Your Next Steps

When design requirements meet the following conditions, the EXB-V4V823JV is an ideal choice: dual resistors with a medium-to-high resistance of 82kΩ are needed, PCB space is limited, the system accuracy tolerates a ±5% tolerance, and the operating environment is standard industrial or consumer-grade. It is recommended to download the official datasheet and PCB footprint library immediately, reserve test points in the design, and verify the thermal drift performance through actual prototyping. Precise selection is the cornerstone of product reliability—act now to let the EXB-V4V823JV provide stable support for your circuit design.

Summary: With its nominal resistance of 82kΩ, dual isolated resistor topology, and compact 0606 package, the EXB-V4V823JV provides electronic engineers with an excellent option that balances performance, space, and cost. In the design environment of 2025, mastering its core parameters and selection logic will make you more confident when facing precision circuit designs. Remember: selection is not simply looking up tables, but a systematic trade-off based on system requirements—this guide is your starting point for taking the correct first step.

Technical FAQ and Troubleshooting Guide

How does the temperature coefficient of resistance (TCR) of the EXB-V4V823JV resistor network perform under extreme temperatures?

The temperature coefficient of resistance (TCR) of the EXB-V4V823JV is ±200ppm/°C. Within the operating temperature range of -40°C to +85°C, its 82kΩ resistance may generate a maximum thermal drift of around 2.05kΩ. While this is sufficient for general industrial control and consumer electronics, evaluation is required for ultra-precision signal acquisition to determine if this drift exceeds the circuit's error tolerance limit.

What is the difference between the isolated (ISOL) topology and the common bussed (BUS) resistor network topology?

In an isolated topology, each internal resistor is completely independent with no common pin. The EXB-V4V823JV contains 2 independent resistors, achieving perfect electrical isolation and eliminating inter-channel high-frequency signal intermodulation interference. It is highly suitable for differential amplifiers, voltage dividers, or precision dual-channel feedback networks. Conversely, bussed topologies, due to a shared ground or power terminal, are highly prone to introducing parasitic signal coupling.

How does the 0606 package of the EXB-V4V823JV maintain solder joint reliability in industrial vibration environments?

The device adopts a miniature 0606 (1.6mm × 1.6mm) package with high lead coplanarity, perfectly matching standard SMD reflow soldering. However, for use on industrial control motherboards subjected to strong vibrations and high impacts, it is recommended to leave sufficient micro-solder joint clearance during land pattern design, or reinforce with underfill or red glue after SMT mounting to resist mechanical stress fatigue.

Why does the thick film process of the EXB-V4V823JV offer greater advantages in harsh environments compared to standard thin film resistors?

The EXB-V4V823JV utilizes Panasonic's unique thick-film anti-sulfurated material process. In heavy industrial or automotive electronics environments containing corrosive gases like sulfur dioxide or hydrogen sulfide, thin film resistors are prone to open circuits caused by silver electrode sulfuration. In contrast, the thick film process offers exceptional environmental tolerance, thereby significantly enhancing the lifecycle reliability of the product.
