In recent years, smart home, also known as smart house, has appeared in people's vision. Generally speaking, it is a networked and intelligent home control system integrating automatic control system, computer network system and network communication technology. Smart home system is based on the residential platform and controls all appliances connected to the home network through mobile app.   Smart home includes eight subsystems; The purpose of these systems is to bring people a safe, convenient, comfortable, artistic, environment-friendly and energy-saving living environment. Smart home not only needs convenient and intelligent control program in software, but also needs to ensure the normal operation of smart home system in hardware.   In this case, various inductors must be used in the circuit to collect data. In addition, there are protection circuit, oscillation circuit, power supply circuit, power amplification circuit and filter circuit; These circuits are without exception, and inductors are one of the indispensable electronic components.   So, what is the role of plug-in power inductors in smart home scenarios?   Current blocking effect: the self induced electromotive force in the coil always opposes the current change in the coil. It can be mainly divided into high-frequency choke coil and low-frequency choke coil.   Tuning and frequency selection: LC tuning circuit can be formed by connecting inductance coil and capacitor in parallel. That is, if the natural oscillation frequency f0 of the circuit is equal to the frequency f of the non AC signal, the inductive reactance and capacitive reactance of the circuit are also equal, so the electromagnetic energy oscillates back and forth between the inductance and capacitance, which is the resonance phenomenon of the LC circuit. During resonance, because the inductive reactance and capacitive reactance of the circuit are equivalent and reverse, the inductive reactance of the total circuit current is the smallest and the current is the largest (referring to the AC signal of f=f0), so the LC resonant circuit has the function of selecting the frequency and can select the AC signal of a certain frequency f.
2024-06-28 11:39:06 1
Linear integrated circuit is an integrated circuit based on amplifier. The word "linear" means that the response of the amplifier to the input signal usually presents a linear relationship. Later, this kind of circuit includes many nonlinear circuits such as oscillator, timer and data converter, as well as the circuit combining digital and linear functions. Because the information processed involves continuously changing physical quantities (analog quantities), people also call this kind of circuit analog integrated circuit.   In terms of manufacturing process, most linear integrated circuits are manufactured by standard bipolar process. In order to obtain high-performance circuits, some modifications or additional manufacturing processes are sometimes made on the basis of standard processes, so as to make various components and devices with different performances on the same chip.   Linear integrated circuits are generally manufactured by standard bipolar process. In order to obtain high-performance circuits, some modifications or additional manufacturing processes are sometimes made on the basis of standard processes, so as to make various components and devices with different performances on the same chip. The technology of making high performance junction field effect transistor on bipolar chip.   When the NPN tube on the chip is formed, the low concentration p-type channel and high concentration n+ type gate region are formed by doping with two ion implantation techniques respectively. The gate drain breakdown voltage can reach 50 ~ 60 VOLTS, and the pinch off voltage can be controlled at about 1 volt. The common breakdown diode uses the EB junction of NPN transistor, and its breakdown phenomenon occurs on the junction surface.   The subsurface breakdown diode is a high concentration p+ layer made by ion implantation under the n+ emission region, and an n+-p+ junction is formed deep below the surface. The breakdown voltage of this transistor is lower than that of the surface junction, the breakdown process is not affected by the surface condition, the noise is low, and it has good long-term stability.
2024-06-28 11:37:26 1
An operational amplifier can be thought of as a simple box or block containing an amplifying device, such as a bipolar transistor, a field effect transistor, or an operational amplifier, which has two inputs and two outputs (grounded), the output signal being much larger than the input signal because it has been "amplified".   Operational amplifier has two power supply modes, dual power supply and single power supply. For an operation with dual power supply, the output value can be changed up or down at zero voltage, or the output can be set to zero at zero differential input voltage. For single-supply operation, the output value is only allowed to change within a certain range between the power supply and the ground.   For general Operational Amplifiers, the input potential is required to be in the range from a certain value above the negative power supply to a certain value below the positive power supply, but it can also be changed from a negative power supply to a positive power supply in the whole range after special design, even slightly higher or lower than the positive power supply. This kind of operation amplifier is called track-to-track input Operational Amplifier.   operational amplifier are generally considered to have the following characteristics:   Infinite open-loop gain G = V out / V in   The input impedance R in is infinite, so the input current is zero   Zero Input Misalignment Voltage   Infinite output voltage range   Infinite bandwidth with zero phase shift and infinite swing rate   Zero output impedance R out   Zero noise   Infinite common mode rejection ratio (CMRR)   Infinite power rejection ratio.
2024-06-28 11:36:35 1
EEPROM is a live erasable programmable read-only memory. It is a memory chip with no data loss after power failure. EEPROM can erase existing information and reprogram it on a computer or on a dedicated device. Usually used for Plug and Play.   EEPROM (charged erasable programmable read-only memory) is a user-modifiable read-only memory (ROM), which can be erased and reprogrammed (rewritten) by higher than normal voltage. Unlike EPROM chips, EEPROM can be modified without having to be removed from the computer. In an EEPROM, the life of the EEPROM is an important design consideration because the computer can be programmed repeatedly when it is in use. EEPROM is a special form of flash memory that is typically used to erase and reprogram voltage from a personal computer   The writing process of EEPROM takes advantage of the tunnel effect that electrons with less energy than the energy barrier can cross the barrier to the other side. Quantum mechanics assumes that electrons fluctuate when the physical size is equal to the free path of the electron, which means that the object is small enough.   As far as the P n junction is concerned, when the impurity concentration of P and N reaches a certain level and the space charge is very small, the electrons will migrate due to the tunnel effect guide band. The range in which the energy of an electron is at an allowable level is called a band, the lower band is called a valence band, and the higher band is called a conduction band. When an electron reaches a higher conduction band, it can move freely between atoms, which is the current.   Due to the inconvenience of EPROM operation, the BIOS ROM chips on the motherboard are mostly EEPROM (Electrical Erasable Programmable ROM).   EEPROM erase does not need to use other devices, it uses electronic signals to modify its contents, and uses Byte as the smallest unit of modification, so it can write without washing out all the data, completely breaking away from the constraints of EPROM Eraser and the programmer.
2024-06-28 11:35:41 1
A transformer is a static electromagnetic device that converts electrical energy from one value to another. Basically, the transformer consists of an iron core and two coils called primary and secondary windings.   Transformer is a device that transforms AC voltage, current and impedance. When AC current is connected in the primary coil, AC magnetic flux will be generated in the iron core (or magnetic core), causing voltage (or current) to be induced in the secondary coil. The transformer is composed of an iron core (or magnetic core) and a coil. The coil has two or more windings, of which the winding connected to the power supply is called the primary coil, and the other windings are called the secondary coil.   The changing current in one coil of the transformer produces a changing magnetic flux, and then induces a changing electromotive force on the second coil wound on the same iron core. Electric energy can be transmitted between two coils, and there is no metal connection between the two circuits. The transformer can increase or decrease voltage and current levels without changing the frequency.   However, the winding process of transformer will have different requirements according to different applications (different purposes). The main functions of the transformer are: voltage transformation; Impedance transformation; Isolation; Voltage stabilization (magnetic saturation transformer), etc. the commonly used iron core shapes of transformers generally include E-type and C-type iron cores.   Transformers can be divided into: distribution transformer, power transformer, fully sealed transformer, combined transformer, dry-type transformer, single-phase transformer, electric furnace transformer, rectifier transformer, reactor, transformer, anti transformer, lightning transformer, box transformer, box transformer.   The most basic type of transformer consists of two groups of coils wound with wires, which are inductively combined with each other. When an AC current (with a certain known frequency) flows through one group of coils, an AC voltage with the same frequency will be induced in the other group of coils, and the magnitude of the induced voltage depends on the coupling of the two coils and the degree of magnetic cross-linking.
2024-06-28 11:34:41 0
Complex programmable logic device (CPLD) was developed in the mid-1980s with the continuous improvement of semiconductor component technology and the continuous improvement of user requirements for device integration.   There are many manufacturers of complex programmable logic devices (CPLD), with various varieties and structures, but most of them adopt the following two structures. One is CPLD based on product term. The logic unit of this CPLD follows the product term logic unit structure of simple PLD (pal, gal, etc.). At present, most CPLDs belong to this type.   The logic block in CPLD is similar to a small-scale PLD. Usually, a logic block contains 4 ~ 20 macro units, and each macro unit is generally composed of product term array, product term allocation and programmable registers.   So, what are the application scenarios of complex programmable logic devices?   The emergence of reconfigurable PLD (programmable logic device) based on SRAM (static random access memory) has created conditions for system designers to dynamically change the logic function of PLD in operating circuits.   PLD uses SRAM units to store configuration data. These configuration data determine the interconnection relationship and logic function within the PLD. Changing these data also changes the logic function of the device.   Since the data of SRAM is volatile, these data must be stored in non-volatile memory such as EPROM, EEPROM or Flash ROM other than PLD devices, so that the system can download them to the SRAM unit of PLD at an appropriate time, so as to realize in circuit Reconfigurability (ICR).
